Symbol : 15533
Dostupnost:
1596
opak
: 364.16
: 364.16
| Model | DH-PFM920I-5EUN |
| Conductor | |
| Material | OFC(oxygen free copper) |
| Composition | 1/0.45 |
| Wire gauge | 0.45*4P0.005mm |
| Insulation | |
| Material | HDPE |
| Min. average thickness | 0.2mm |
| Diameter | 0.83mm0.03mm |
| Color(4 Pairs) | Orange, white/orange; green, white/green; blue, white/blue; brown, white/brown |
| Lay of twisted conductors | 140mm |
| Jacket | |
| aterial | PVC, meet the requirement of CPR E class |
| Min. average thickness | 0.5mm0.05mm |
| Diameter | 4.7mm |
| Color | White |
| Length | 305m (1000.66ft) |
| Max. DC resistance of single conductor | 12 Ω/100m |
| Max. unbalance rate of line pairs' direct current resistance | 0.12 |
| Min. insulation resistance | 5000MΩ·km |
| Max. mutual capacitance | 5.6NF/100m |
| Max. attenuation | 22(dB/100m, 100MHz) |
| General | |
| N.W. | 7.8kg |
| Packaging dimension | 360mmx360mmx220mm |
| Weight (with packaging) | 8.6kg |
